Rear Axle Support for 2006 Mercedes-Benz S430
No.
Part # / Description / Price
Price
15
1954-2025 Mercedes-Benz - Spring Link Bushing
Mercedes-Benz
Mercedes-Benz Notes: THE OLD PART MUST NO LONGER BE INSTALLED
Description: Spring control arm to rear subframe. Spring link to rear axle bracket left.
MSRP $39.50
$29.38
MSRP $39.50
$29.38
15
Spring Link Bushing Mercedes-Benz
Mercedes-Benz Description: Spring control arm to rear subframe. Spring link to rear axle carrier. Spring link to rear axle bracket left.
20
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Axle casing to rear axle bracket left rear. Axle housing to rear subframe,rear.
MSRP $62.00
$46.25
MSRP $62.00
$46.25
25
Window Mercedes-Benz
Mercedes-Benz Description: In floor,above rear rear axle d=26 mm. For cover plate. In rear end floor.
MSRP $3.40
$2.72
MSRP $3.40
$2.72
35
MSRP $7.75
$6.26
40
Screw Mercedes-Benz
Mercedes-Benz Description: Rear subframe to frame floor unit, front. M12 x 1.5 x 86.5. To frame base front.
MSRP $11.50
$9.11
MSRP $11.50
$9.11
50
MSRP $248.00
$179.08
110
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Extension to rear subframe,front. M14x90.
120
1954-2020 Mercedes-Benz - Window Mercedes-Benz
Mercedes-Benz Description: Spring control arm to wheel bearing. Spring link to wheel carrier. Suspension strut to spring control arm at left. Hydropneumatic spring leg to spring control arm. Spring control arm to rear subframe.
MSRP $2.70
$2.18
MSRP $2.70
$2.18
130
MSRP $8.00
$6.53
180
1954-2026 Mercedes-Benz - Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 1 mm. Differential to cross stabilizer front 1 mm. 1 mm. Rear axle differential to front cross brace 1 MM. 1 MM. As required 1.0 mm. 1 mm. As required, no. Of notches:. 1 mm. As required 1.00 mm. 1 mm.
MSRP $4.70
$3.81
MSRP $4.70
$3.81
180
1954-2026 Mercedes-Benz - Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 4 mm. Differential to cross stabilizer front 4 mm. 4 mm. Rear axle differential to front cross brace 4 MM. 4 MM. As required 4.0 mm. 4 mm. As required, no. Of notches:. 4 mm. As required 4.00 mm. 4 mm.
MSRP $5.75
$4.62
MSRP $5.75
$4.62
180
1954-2026 Mercedes-Benz - Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 3 mm. Differential to cross stabilizer front 3 mm. 3 mm. Rear axle differential to front cross brace 3 MM. 3 MM. As required 3.0 mm. 3 mm. As required, no. Of notches:. 3 mm. As required 3.00 mm. 3 mm.
MSRP $6.00
$4.90
MSRP $6.00
$4.90
180
1954-2026 Mercedes-Benz - Spacer Disk Mercedes-Benz
Mercedes-Benz Description: Adapter to rear axle centerpiece. 2mm. Differential to cross stabilizer front 2mm. 2mm. Rear axle differential to front cross brace 2mm. 2mm. As required 2.0 mm. 2mm. As required, no. Of notches:. 2mm. As required 2.00 mm. 2mm.
MSRP $5.50
$4.35
MSRP $5.50
$4.35
190
1960-2025 Mercedes-Benz - Window Mercedes-Benz
Mercedes-Benz Description: Mounting parts. Fastening parts to spring link.
MSRP $2.20
$1.77
MSRP $2.20
$1.77
200
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Steering to frame m 12x90. M12X1,5X90
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing to rear subframe,rear.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Axle housing to rear subframe,rear.
MSRP $22.50
$17.15
MSRP $22.50
$17.15
